US Motors 5461 Rescue 5.6″ Direct Drive Blower Motor, 208-230V, 1/2-1/6 HP, 1075 RPM

The Ultimate Truck Stock Motor

What is a Rescue Motor?

• Universal Replacement Motor for Condenser Fan and Direct Drive Blower Applications
• Multi-Horsepower PSC Motors
• Flexible Mounting Options
• Permanent Replacement Motors There is no need to go back
• Designed to Allow Contractors to Stock Fewer Motor Models On Their Truck While Increasing the Service Level to Their Customers

How Does Multi Horsepower Work?

• A PSC Motors output RPMs vary based upon the driven load.
• Increases in loading will reduce the RPMs
• Decreases in loading will increase the RPMs towards Synchronous
• Specifically Designed Motor Windings and Speed Taps to Match HP Requirements and Speed for Each Application.
• Each Motor has More Copper (Windings) and Iron (Rotor Core) to Prevent Overheating.
• This Makes RESCUE Motors Stronger

Direct Drive Blower Motor Features

• Permanent Split Capacitor (PSC) Design
• Open Air Over (OAO)
• Automatic Thermal Protector
• Self – Aligning Sleeve Bearing
• Reversible Rotation
• 36 Inch Leads
• All Angle Mounting Vertical or Horizontal
• Mounts by Thru-bolts, Belly Band (With Kit), or Eight Holes in the Shell for Brackets, Including Rheem and Trane Special Mounting

Dimension Print
